1) CH-13 BMW (USED) 11002288240 N20B20 ENGINE TWIN SCROLL TURBO FROM: BMW (USED) K689994 2016 320i xDrive FITS: F30 F31 F34GT F32 F36 Euro All Parts

LOCATION:CH-13

HAS NEW VALVE COVER

CH

BMW 11002288240

N20B20

 ENGINE TWIN SCROLL TURBO

FROM: BMW K689994 2016 320i xDrive

FITS: F30 F31 F34GT F32 F36

XXXXXXXXXXXXXXXX______XXXXXXXXXXXXXXXXXX

Scroll down for more details or e-mail your questions to: info@euroallparts.com

ENGINE:
Manufacturer    BMW
Production    2011-2017
Layout
Configuration    Inline-4
Displacement    1,592 cc (97 cu in)
1,997 cc (122 cu in)
Cylinder bore    84.0 mm (3.31 in)
Piston stroke    71.8 mm (2.83 in)
90.1 mm (3.55 in)
Block material    Aluminium
Head material    Aluminium
Valvetrain    DOHC, with VVT & VVL
Combustion
Turbocharger    Single twin-scroll
Fuel type    Gasoline

11002420321
Short Engine
N20B20B

From:
    01/01/2016
To:
    -
Weight:
    0.005 kg

Supersedes:

11002288240
    (07/02/2012 — 02/25/2016), Exchangeable retrospectively
11002349220
    (07/02/2012 — 02/02/2016), nonexchangeable retrospectively
11002444998
    (02/01/2016 — )

Part 11002420321 was found on the following vehicles:

    3' F30   (05/2011 — 07/2015)
    3' F30 LCI   (03/2015 — 10/2018)
    3' F31   (01/2012 — 06/2015)
    3' F34 GT   (11/2012 — 06/2016)
    4' F32   (04/2013 — 02/2016)
    4' F36 Gran Coupé   (11/2013 — 02/2016)
The BMW N20 is a 1.6 and 2.0 L (98 and 122 cu in) turbocharged four-cylinder DOHC petrol engine with variable valve lift and variable valve timing which replaced the N53 (or BMW N52 in some markets) and was produced from 2011 to 2017 by BMW. Although the N20 is a four-cylinder engine, it is considered a replacement for the naturally aspirated six-cylinder N52/N53 because it powers equivalent models, producing similar horsepower to the N52/N53 with greater low-rpm torque and better efficiency.[1]

The N20 features a twin-scroll turbocharger, double-VANOS (variable valve timing), Valvetronic (variable valve lift), direct injection, automatic stop-start[2] and an electric water pump. The N20 was sold alongside the smaller displacement BMW N13 turbocharged four-cylinder engine. The N20 was placed in Wards Top 10 Engines in 2012.



Engine 110510 - BMW (11-00-2-420-322)

Genuine BMW Rp Engine 110510 - Part Number 11-00-2-420-322
Replaces 11-00-2-420-321
110510 - BMW (11-00-2-420-322)

BMW DEALER LIST PRICE FOR FACTORY REBUILD: $7,542.25 SHORT BLOCK + CORE
WE DO NOT CHARGE CORE
    SKU: 11-00-2-420-322 Replaces: 11-00-2-288-240, 11-00-2-288-241, 11-00-2-349-220, 11-00-2-349-221, 11-00-2-420-321


N20B20     1,997 cc (121.9 cu in)
135 kW (181 bhp)at 5,000 rpm
270 N⋅m (199 lb⋅ft)at 1,250-4,500 rpm     7,000
PRODUCTION DATES: 2011–2017

N20B20
Applications
135 kW version
    2011–2015 E84 X1 xDrive/sDrive20i
    2011–2017 F25 X3 xDrive20i
    2012–2015 F30 320i
    2013–2016 F34 320i GT
    2014–2016 F32 420i
    2011–2016 F10 520i
    2013-2016 F10 520Li
    2011–2016 E89 Z4 sDrive20i
    2014–2016 F22 220i
    2015-2017 Brilliance Huasong 7 MPV

- If you have question regarding: fitment, availability, condition, delivery or any other question about this or any other part, please e-mail us: " info@euroallparts.com "
